Log Number: 4456602Logbook(s):

• POLOG
• ELOG

Entry Makers: chgarciaBody:

The CEBAF Gun HVPS SF6 tank relief valve swap job started today. The existing valve is past due certification. A certified valve is on hand and ready for installation. See pre-job briefing completed on Sept-4-2025 under Attachments in ATLIs 117151.

First Jessica craned the DILO cart from the ISB down to the injector tunnel.

Next, we connected the DILO cart to the ball valve at the bottom of the HVPS SF6 tank, and evaucated the hose per DILO cart instruction manual.

Log Number: 4456600Logbook(s):

• ELOG

Body:

Disconnected waveguides on cavities 1/2 and 7/8 and installed blanker plates as well as PSS lock bolts. Will need to continue to complete cavities 3/4 and 5/6 on the backside of the cryo-module. Techs: C. Kerns, L. Farrish and Adam Schoener. Personal locks removed from MDP breaker and in-line dump.

Log Number: 4456598Logbook(s):

• ELOG

Body:

Discussed 10A and 20A PM checklist with the work teams.

Log Number: 4456597Logbook(s):

• ELOG

Body:

A lot of the supporting circuitry has been removed from the CPS. H V Capacitor has been dis-connected and a shorting wire installed. Bleeder bank and step start resistors removed. H V shorting solenoid and 50 ohm resistors removed. Incoming line reactor as well as the power factor correction circuit dis-connected. Step start and Main contactors disconnected from circuits. Techs: E. Valentine, A. Shenenberger, and S. Holben

Log Number: 4456595Logbook(s):

• ELOG

Body:

Task approved by work supervisor.

Log Number: 4456594Logbook(s):

• ELOG

Body:

Task approved by work supervisor.

Log Number: 4456593Logbook(s):

• ELOG
• SRFLOG

Body:

AE Line:
- Valves disconnected
- Ion pump power down, venting to start tomorrow morning

Injector:
- Two flapper valve, N2 bleed up planned for IHA0L03 soon

BSY:
- 1C beamline to Hall A disconnected
- Replacement with beamline spool in progress

Log Number: 4456592Logbook(s):

• ELOG
• ACELOG

Body:

Complete,
Upstairs cable installed to CST network switch. Pink cable downstairs connected to patch panel. Verified connection back to switch.

Log Number: 4456591Logbook(s):

• ELOG
• RFLOG

Body:

Disconnected CPS Interlock Cables & CPS Digital Cables from both TB-3 & TB-4 in the CPS Terminal Cabinet (B20) which will no longer be used.

Log Number: 4456590Logbook(s):

• ELOG

Body:

Network cable installed.
Upstairs cable installed to CST network switch. Pink cable downstairs connected to patch panel. Verified connection back to switch.

Log Number: 4456589Logbook(s):

• ELOG

Body:

Cable staged and ready for pull. In light of active shooter drill and the flush cart in the area of EA6-SL01, we'd like to wait until wednesday before pulling.

Log Number: 4456588Logbook(s):

• ELOG

Body:

We would like to start this task on Wednesday, 09/10 at 0930. We will start in B67. Pumps will be placed in Hand as needed so flow will not be affected. System temperature may drop below normal setpoint (95F) when control valves are stroked to full open given there is little (or no) heat load on the system.

Log Number: 4456583Logbook(s):

• ELOG
• INCLOG

Body:

CIS group transferred Ion pumps VIP2I00 - 1I01A from UHV supplies and placed on local holding supplies
( https://tasklists.jlab.org/atlis/tasks/117887 )

Removed decommissioned UHV supplies from rack IN02B27. Supplies brough back to injector lab to be used as spares for UITF.

Installed 4-shelf unit in rack and populated with new Gamma SPCe ion pump power supplies.
Should be able to transfer the ion pumps off the holding supplies to the new Gammas as soon as CIS is ready.
(Note that there will still be no remote monitoring of these pumps until control modifications are fully complete.)

Log Number: 4456581Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2025-09-08 15:18:29 The output from the myRestore execution was as follows: iocsoftw3spce systemEnum@2025-09-08 15:18 2(2) restored Execute: /usr/csite/certified/bin/ced2Epics -ced ced -A -i iocsoftw3spce (success) PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 Procedure return status: Success

Log Number: 4456579Logbook(s):

• ELOG

Body:

Valves disconnected and closed in preparation for AE line vent and removal. Ion pumps will be powered down in the morning before venting.

Log Number: 4456577Logbook(s):

• ELOG

Body:

8th September work:
- L2He cryomodule 22R final survey;
- C75-05 cryomodule fiducialization;
- Hall D Microscope as-found.

9th September work map:
- (ESB building) Hall B P-RAD target fiducialization;
- SW corner RF separators as-found.

Log Number: 4456575Logbook(s):

• ELOG

Body:

Replaced Agilent scroll pump (NA) at 2L25 gate valve open turbo at full speed. Pump (F227890) staged for RADCON survey.

Log Number: 4456574Logbook(s):

• ELOG

Body:

300k warm-up in progress. Actively pumping on 1L04,1L05&1L06 beamline.

Log Number: 4456573Logbook(s):

• ELOG

Body:

Penje. 2584 & 2586 emptied.

Log Number: 4456572Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2025-09-08 13:31:24 The output from the myRestore execution was as follows: iocnl24rfcry <NOTE> iocnl24rfcry: Provided macro *BLDGNUM* is never used <NOTE> iocnl24rfcry: Provided macro *ZONE* is never used systemEnum@2025-09-08 13:31 2(2) restored Execute: /usr/csite/certified/bin/ced2Epics -ced ced -A -i iocnl24rfcry (success) PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 Procedure return status: Success
