Log Number: 4495731Logbook(s):

• ELOG
• BTLOG

Tags:

• Autolog

Body: eDT V2-41 Design Setpoints Download

hostname: opsl04
CED workspace: OPS
CED login_key: pro


CHANNELNEW VALUEOLD VALUEMQA9S02.BDL-14840.2817-11103.2461MQA9S03.BDL11969.599616830.6543MQA9S04.BDL-4612.5254-13776.4473MQA9S05.BDL8185.6769-3944.5498MQA9S06.BDL-7433.7840-20179.0332

Log Number: 4495730Logbook(s):

• ELOG
• BTLOG

Body: Fopt results from /usr/ntfs/public/optics/diforb/26may061853
Comment: to 9R
HOSTNAME: opsl02
CED WORKSPACE: OPS CED LOGIN KEY: pro
MYA DEPLOYMENT: ops
CONFIG PATH: /cs/prohome/apps/q/QTSnyder_QT5/1-2/fileio/config/cs.conf
DIFORB PATH: /usr/ntfs/public/optics/diforb

Log Number: 4495729Logbook(s):

• ELOG

Entry Makers: alexsBody:

Log Number: 4495728Logbook(s):

• ELOG
• BTLOG

Tags:

• Autolog

Body: dogCalc V0-14 download

hostname: opsl01
CED workspace: OPS
CED login_key: pro

Log Number: 4495727Logbook(s):

• ELOG

Tags:

• Autolog

Body: Fopt 7.9 completed successfully. The runtime settings include a sample count of 15, a minimum current of 4, and an operating regime of Standard with Excitation in 1S Region. The corrector and RF kicks applied were 0.488208 and 0.488208 volts respectively. The max. amplitude setting was 1 millimeters. The files for this run were saved in the directory /cs/opshome/hlapps/optics/diforb/26may061853. The X and Y stability of the machine during the run was 0.0429972 and 0.0600035 (mm) respectively.

Log Number: 4495726Logbook(s):

• BTLOG
• ELOG

Entry Makers: shrinerBody:

Log Number: 4495725Logbook(s):

• BTLOG
• ELOG

Entry Makers: alexsBody:

Found large CS growth in 8L and large DiffX orbit after most recent FOPT. Used MQA7R01 to do a ballpark recombiner match, and significantly improved optics parameters.

Log Number: 4495724Logbook(s):

• BTLOG
• ELOG

Entry Makers: shrinerBody:

Log Number: 4495723Logbook(s):

• ELOG

Body:

Comments:

after 7R recombiner match

Laser Used:

D Laser

Sigmas:

Peak 1 - x Sigma: 0.1076 Peak 2 - u Sigma: 0.2173 Peak 3 - y Sigma: 0.2106

Log Number: 4495722Logbook(s):

• ELOG
• BTLOG

Body: Fopt results from /usr/ntfs/public/optics/diforb/26may061834
Comment: to 8R after 7R recombiner match
HOSTNAME: opsl02
CED WORKSPACE: OPS CED LOGIN KEY: pro
MYA DEPLOYMENT: ops
CONFIG PATH: /cs/prohome/apps/q/QTSnyder_QT5/1-2/fileio/config/cs.conf
DIFORB PATH: /usr/ntfs/public/optics/diforb

Log Number: 4495721Logbook(s):

• ELOG

Tags:

• Autolog

Body: Fopt 7.9 completed successfully. The runtime settings include a sample count of 15, a minimum current of 4, and an operating regime of Standard with Excitation in 1S Region. The corrector and RF kicks applied were 0.488208 and 0.488208 volts respectively. The max. amplitude setting was 1 millimeters. The files for this run were saved in the directory /cs/opshome/hlapps/optics/diforb/26may061834. The X and Y stability of the machine during the run was 0.0364017 and 0.0459031 (mm) respectively.

Log Number: 4495720Logbook(s):

• ELOG

Body:

HYST AREA Version 7-0 has successfully cycled the following:

MQA7R01
MQA7R02
MQA7R03
MQA7R04
MQK7R05
MQR7R06
MQK7R07
MQK7R08
MQK7R08A
MQR7R09
MQA7R10

Total Time: 0.500 mins

Log Number: 4495719Logbook(s):

• BTLOG
• ELOG

Entry Makers: dturnerBody:

We have beam at 8R. We haven't had to adjust anything until now. The horizontal betatron match is blown out of 7R into 8L as shown on fopt. We will attempt a 7R recombiner match to correct. The 7R betatron tuning quads were on design when the fopt was taken.

Eight out of ten isn't bad...

Log Number: 4495718Logbook(s):

• ELOG

Entry Makers: alexsBody:

Going to need optics touch ups in 7R based on the FOPT, so taking care of Arc 8 path length before we start

Log Number: 4495717Logbook(s):

• ELOG
• BTLOG

Body: Fopt results from /usr/ntfs/public/optics/diforb/26may061814
Comment: to 8R
HOSTNAME: opsl02
CED WORKSPACE: OPS CED LOGIN KEY: pro
MYA DEPLOYMENT: ops
CONFIG PATH: /cs/prohome/apps/q/QTSnyder_QT5/1-2/fileio/config/cs.conf
DIFORB PATH: /usr/ntfs/public/optics/diforb

Log Number: 4495716Logbook(s):

• ELOG
• BTLOG

Tags:

• Autolog

Body: dogCalc V0-14 download

hostname: opsl01
CED workspace: OPS
CED login_key: pro

Log Number: 4495715Logbook(s):

• ELOG

Tags:

• Autolog

Body: Fopt 7.9 completed successfully. The runtime settings include a sample count of 15, a minimum current of 4, and an operating regime of Standard with Excitation in 1S Region. The corrector and RF kicks applied were 0.488208 and 0.488208 volts respectively. The max. amplitude setting was 1 millimeters. The files for this run were saved in the directory /cs/opshome/hlapps/optics/diforb/26may061814. The X and Y stability of the machine during the run was 0.0619474 and 0.0729559 (mm) respectively.

Log Number: 4495714Logbook(s):

• BTLOG
• ELOG

Entry Makers: shrinerBody:

Log Number: 4495713Logbook(s):

• ELOG

Body:

Laser Used:

D Laser

Sigmas:

Peak 1 - x Sigma: 0.2401 Peak 2 - u Sigma: 0.3310 Peak 3 - y Sigma: 0.2476

Log Number: 4495712Logbook(s):

• ELOG

Entry Makers: alexsBody:

Gang phase was fine
