Log Number: 4404503Logbook(s):

• ELOG

Entry Makers: bschaumlBody:

We got a smattering of alarms in the MCC for power, magnets, and cryo. Seems like the magnet drops were concurrent with some disturbance to voltage at the CUP. While recovering the magnets facilities informed us that they lost several chillers. We also saw service building temps start to rise dramatically so we decided to turn off box supplies. Currently monitoring other temperatures for other systems/buildings.

Log Number: 4404502Logbook(s):

• ELOG

Body: IDDescriptionPeriodCause 14998Title:
loss of chilled water

Summary:
MCC was contacted re: power issue in CUP affecting chilled water on site; temperatures in service buildings are rapidly rising. Facilities is responding.

Log Number: 4404501Logbook(s):

• DCLOG
• ELOG

Entry Makers: msmithBody:

Took setpoint and cycled

Log Number: 4404498Logbook(s):

• ELOG

Tags:

• Autolog

Body:

The following box supplies were TURNED OFF by version 2-16 of the Box Supply Cycling Script:
ARC1A Ramp Rate = 8.126 A/s
ARC2A Ramp Rate = 7.364 A/s
ARC3A Ramp Rate = 10.301 A/s
ARC4A Ramp Rate = 11.347 A/s
ARC5A Ramp Rate = 10.439 A/s
ARC6A Ramp Rate = 9.733 A/s
ARC7A Ramp Rate = 10.490 A/s
ARC8A Ramp Rate = 12.281 A/s
ARC9A Ramp Rate = 9.900 A/s
ARCAA Ramp Rate = 12.593 A/s
BSY1C Ramp Rate = 10.406 A/s
BSY2C Ramp Rate = 10.147 A/s
BSY3C Ramp Rate = 3.819 A/s
DOG1E Ramp Rate = 3.856 A/s
DOG2E Ramp Rate N/A
DOG3E Ramp Rate N/A
DOG4E Ramp Rate N/A
DOG5E Ramp Rate N/A
DOG6E

Log Number: 4404500Logbook(s):

• ELOG

Entry Makers: jhowardBody:

Called by facilities after some sort of power issue. Turning off box supplies just to be safe, and contacting DC Power for further guidance while chillers are worked on.

Log Number: 4404496Logbook(s):

• ELOG

Body: IDDescriptionPeriodCause 14997Title:
Recovering Magnets

Summary:
Hall D sweeper magnet trip. Lam1C trip. QF3M01 Moller quad trip. Cryo CTF alarms.

Log Number: 4404492Logbook(s):

• ELOG

Tags:

• Autolog

Body:

The following box supplies were CYCLED by version 2-16 of the Box Supply Cycling Script:
LAM1C Ramp Rate = 11.793 A/s
LAM3C Ramp Rate = 12.011 A/s

Log Number: 4404491Logbook(s):

• ELOG

Tags:

• Autolog

Body:

The following box supplies were CYCLED by version 2-16 of the Box Supply Cycling Script:
LAM1C Ramp Rate = 12.120 A/s
LAM3C Ramp Rate = 12.011 A/s

Log Number: 4404486Logbook(s):

• ELOG

Body: IDDescriptionPeriodCause 14997Title:
Recovering Magnets

Summary:
Hall D sweeper magnet trip Lam1C trip QF3M01 Moller quad trip Cryo CTF alarmsDuration:
10 minutes

Time Down:
24-Jun-2025 04:26

T

Log Number: 4404475Logbook(s):

• ELOG
• RFLOG

Entry Makers: kpriceBody:

Detune angle was hanging out around -8 degrees and reacting significantly to beam trips. Just tried bringing it back to zero to see if that helps. I think it needs the attenuator opened up a wee bit as well. Don't mind the wiggly GMES - 2L20 is an active lock zone.

Log Number: 4404461Logbook(s):

• POLOG
• ELOG

Entry Makers: kpriceBody:

error was accumulating on B attenuator especially. Took the opportunity to clear it by homing all the attenuators following the QE.

Log Number: 4404458Logbook(s):

• DCLOG
• ELOG

Body: IDDescriptionPeriodCause 14996Title:
MBC4A15H trimcard swap

Summary:
MBC4A15H would not take setpoint.

Log Number: 4404457Logbook(s):

• POLOG
• ELOG

Body: Spot Location: (14500,19000), Charge: 116.04134999999998

Laser Wavelength Atten Setting Laser Power Current HV PS Current QE PV Updated? Update Time/Reason Not Updated (nm) (W) (uA)</

Log Number: 4404456Logbook(s):

• ELOG

Tags:

• Autolog

Body: System UN-Masking for: CryoModule
User: kprice
Areas: NorthLinac SouthLinac

CryoModule Devices:
1L14
1L03
1L02
1L04
1L05
1L07
1L06
1L08
1L09
1L10
1L11
1L12
1L15
1L13
1L16
1L19
1L17
1L18
1L20
1L21
1L22
1L23
1L24
1L25
1L26
2L14
2L03
2L02
2L04
2L05
2L07
2L06
2L08
2L11
2L09
2L10
2L12
2L15
2L13
2L16
2L19
2L17
2L18
2L20
2L21
2L22
2L23
2L24
2L25
2L26

Log Number: 4404455Logbook(s):

• ELOG

Body:

HYST AREA Version 7-0 has successfully cycled the following:

MQC2A19
MBT2A19V
MBC8A13H
MBDAA13H
MBDAA14V
MQC2A18
MBT2A18H
MQA4A15
MBC4A15H
MQA6A15
MBC6A15H
MBDAA15H
MBC8A15H
MQC2A17
MBT2A17V
MQA4A14
MBC4A14V
MQA6A14
MBC6A14V
MQA8A14
MBC8A14V
MQC2A16
MBT2A16H
MQA4A13
MBC4A13H
MQA6A13
MBC6A13H
MQA8A13

The following magnets were REMOVED from the CYCLING LIST by the user:
MBC4A15H
Total Time: 0.617 mins

Log Number: 4404454Logbook(s):

• ELOG

Body: IDDescriptionPeriodCause 14996Title:
MBC4A15H trimcard swap

Summary:
MBC4A15H would not take setpoint.

Log Number: 4404451Logbook(s):

• DCLOG
• ELOG

Entry Makers: msmithBody:

Card swapped

Log Number: 4404449Logbook(s):

• ELOG

Tags:

• Autolog

Body: System Masking for: CryoModule
User: jhoward
Areas: NorthLinac SouthLinac

CryoModule Devices:
1L14
1L03
1L02
1L04
1L05
1L07
1L06
1L08
1L09
1L10
1L11
1L12
1L15
1L13
1L16
1L19
1L17
1L18
1L20
1L21
1L22
1L23
1L24
1L25
1L26
2L14
2L03
2L02
2L04
2L05
2L07
2L06
2L08
2L11
2L09
2L10
2L12
2L15
2L13
2L16
2L19
2L17
2L18
2L20
2L21
2L22
2L23
2L24
2L25
2L26

Log Number: 4404435Logbook(s):

• DCLOG
• ELOG

Entry Makers: jhowardBody:

While looking for the cause of the position instabilities, we found MQJ0L04 has a resistance alarm. The voltage is also in alarm and degrading, so we tried swapping the trim card to see if that help, though it seems unlikely this is the cause of our positional problems.

Card swap cleared the voltage alarm. We will continue to monitor.

Log Number: 4404385Logbook(s):

• ELOG

Entry Makers: kpriceBody:

It looks like a few vertical lock BPMs in the early arcs stopped reporting changes (or reported them strangely) for a minute or two around this time. To my eye the lock corrector pattern doesn't look all that different from usual and it only seems to have happened for that one excursion, so this might be a red herring. Fig 1 shows a couple excursions but only the one in the red box coincides with BPM weirdness (I think).
