Log Number: 4404686Logbook(s):

• ELOG

Body: IDDescriptionPeriodCause 14999Title:
1L18 breaker MDP tripped off

Summary:
contacted Facilities.

Log Number: 4404682Logbook(s):

• ELOG

Entry Makers: kernsBody:

Replaced the RFCM for cav. 4 CWVF, BLVF and Arc faults not clearing and when zone recovered into RF and OLT tried, the cavity would not go Xpert mode along with cavity 1 not going to Xpert mode. Dropped it down to Idle at 1330 to re-bypass cavity 1 and both went into Xpert mode when going to fiaments and HV. Only problem is the zone CPS and MDP breakers both tripped again and have to be reset. Got the PTW 7758 to try again to get cavities 1L18-4,6,7,8 back into RF so we aren't one cavity away from beaming.

Log Number: 4404681Logbook(s):

• ELOG
• LLRFLOG
• RFLOG

Entry Makers: mmerz

Log Number: 4404678Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The OPS DRVHs for the following cavities have been updated:
1L04-8
Username: deir
Date/Time: 06-24-25_13:03:49
RF Status: Good
Tuner Status: Good
Comment: DRVH=10.300 Tuner slipping, seems okay at 10.3.
Previous OPS DRVH: 5
Special Instructions:

Log Number: 4404677Logbook(s):

• ELOG

Entry Makers: deirBody:

Turning RF back on after chilled water recovery.

Fig 1: The first recovery of this cavity, it tripped off when it got up to 12.3 MV/m. Tuner behavior seemed normal.

Fig 2: Cav back on at 4.4 MV/m, TDETA at +56 Deg. Tuner walks it +110k steps with no change in TDETA.

Fig 3&4: Open-loop tuned the cavity. Was able to see a response in TDETA, but had to move the tuner a significant number of steps. Recovered at 5 MV/m after OLT and let recover script walk it up to 12.7 MV/m.

Log Number: 4404675Logbook(s):

• ELOG

Body:

This task was created for use during the SAM. Completing the task and making a new one for RUN periods

Log Number: 4404674Logbook(s):

• ELOG

Tags:

• Autolog

Body: Destination Masking to: HallA,HallB,HallC,HallD
User: bjacob

Log Number: 4404672Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
1L18-1
Username: kerns
Date/Time: 06-24-25_12:29:52
RF Status: Bad
Tuner Status: Good
Comment: Unbypassed by GSET 0 program. This Cavity has no KCCU and blowing MDP breaker. Should stay bypassed until T/S
Special Instructions:

Maintenance Tag: Component: Tube

Log Number: 4404671Logbook(s):

• ELOG

Entry Makers: bjacobBody:

Log Number: 4404670Logbook(s):

• ELOG

Entry Makers: samariBody:

Considerably higher than the spikes of the past few weeks (Fig 1), but recovered again.

Log Number: 4404665Logbook(s):

• ELOG
• RFLOG

Entry Makers: dchriBody:

Log Number: 4404661Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavities have been UnGSET 0:
1L18-4
Username: kerns
Date/Time: 06-24-25_12:08:08
RF Status: Good
Tuner Status: Good
Comment: UnGSET 0 - stepped on -100k -
Special Instructions:

Maintenance Tag: Component: Other

Log Number: 4404660Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavities have been UnGSET 0:
1L18-1
Username: kerns
Date/Time: 06-24-25_12:08:08
RF Status: Good
Tuner Status: Good
Comment: UnGSET 0 - stepped on -100k -
Special Instructions:

Maintenance Tag: Component: Other

Log Number: 4404659Logbook(s):

• ELOG
• LERFLOG

Body:  ACCELERATOR OPERATOR SIGN IN FORM OPERATOR:    Christian
DATE:             06/24/2025
SHIFT:               Day

The operator has read the following:

• ELOG
• PD Shift Plan
• Radiation Surveys for PSS Segments in Controlled Access
• PSS Log

Log Number: 4404658Logbook(s):

• ELOG

Tags:

• Readme

Entry Makers: deirBody:

Tuner is slipping, unable to tune it in. It's on and stable at 5 MV/m right now (down 7.7 MV/m) . Updated ODHV.

Leave tuner in manual to prevent further issues.

Log Number: 4404657Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
Zone 1L18
Username: bjacob
Date/Time: 06-24-25_11:53:59
RF Status: Good
Comment: Recovering 1L18
Special Instructions:

Maintenance Tag: Component: Operator Entry - See SME

Log Number: 4404656Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
1L04-8
Username: deir
Date/Time: 06-24-25_11:51:48
RF Status: Good
Tuner Status: Good
Comment: DRVH=5.000 Tuner not moving, Cav limited to 5 MV/m
Special Instructions: Leave tuner in manual

Maintenance Tag:

Log Number: 4404655Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
1L18-8
Username: alexs
Date/Time: 06-24-25_11:51:34
RF Status: Good
Tuner Status: Good
Comment: Un-GSET 0, HV restored
Special Instructions:

Maintenance Tag: Component: Operator Entry - See SME

Log Number: 4404654Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
1L18-7
Username: alexs
Date/Time: 06-24-25_11:51:34
RF Status: Good
Tuner Status: Good
Comment: Un-GSET 0, HV restored
Special Instructions:

Maintenance Tag: Component: Operator Entry - See SME

Log Number: 4404653Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
1L18-6
Username: alexs
Date/Time: 06-24-25_11:51:34
RF Status: Good
Tuner Status: Good
Comment: Un-GSET 0, HV restored
Special Instructions:

Maintenance Tag: Component: Operator Entry - See SME
