Log Number: 4457021Logbook(s):

• ELOG

Body:

Swapped fan tray for IOCIN1B. Thank you to SSG for moving the BLM cables to accommodate.

Log Number: 4457020Logbook(s):

• ELOG
• RFLOG

Body:

AES Electricians have disconnected the AC Lines from the external transformers in 1L09, 1L12, 1L13, & 2L05.
The diode stacks were disconnected from the external transformer and placed in front of 2L05. The bolts for the Transformer that's located inside of 2L05 CPS were removed to prepare for removal.

Log Number: 4457018Logbook(s):

• ELOG

Body:

prepped and ready for next two installs listed in previous comment. Would like to do both tomorrow

Log Number: 4457017Logbook(s):

• ELOG
• LERFLOG

Body:
THOMAS JEFFERSON NATIONAL ACCELERATOR FACILITY
ACCELERATOR OPERATIONS CREW CHIEF SIGN IN FORM

Date : 09-11-25
Time : 15:47:14
Day : Thursday
Shift : Swing

Crew Chief : Merz
Program Deputy: RadCon
Team : C
Arm : RADCON
LERF Operator:
Operators :

This stamp certifies that the above Crew Chief has read/reviewed/received the following:

Log Number: 4457016Logbook(s):

• ELOG

Body:

Calibrations in the NAB are ~60% complete. Pumps are back in automatic. Calibrations are scheduled to resume 9/22.

Log Number: 4457015Logbook(s):

• ELOG

Body:

Ran Cables to NL01B11. Started to splice the cables using a box to contain the splice.

- Kissinger

Log Number: 4457013Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2025-09-11 15:16:50 The output from the myRestore execution was as follows: Failed to set restore status indicator iocr999rffcc1 Rf12Fcc_TestStand c100_rffcc@2025-09-11 15:16 72(72) restored c100_ecal@2025-09-11 15:16 19(19) restored Execute: myRestore -execute -P c100_ecal -t R991_ECAL -m BLDGNUM=9 ZONE=9 CAV=1 (success) c100_ecal@2025-01-16 18:09 19(19) restored Execute: burtwb -r 3 -f /cs/opshome/burt/REBOOT/Rf12Fcc/snap-kc/R991-kc.snap (success) rf2HarvTripOff 1(1) restored

Log Number: 4457012Logbook(s):

• ELOG
• SRFLOG

Body:

Injector
- IHA0L03, IHA0L10 leak checks both look good
- DP Stations reactivation (VDP0L03 and VDP0L10) on hold due to electrical issue, waiting on breaker swap to proceed further

AS_Line through west arc AA_Line
- Ion pumps VIPAS02 to VIPAA18 powered off
- Vent scheduled for tomorrow morning

2L18
- Waveguide turbo pump restarted, not dead after all
- Gate valve open, turbo at full speed

Log Number: 4457011Logbook(s):

• ELOG

Body:

I was able to repair most phones in the tunnel today. There are currently 16 phones that have bad lines and will need the phone tech to come repair.

Log Number: 4457010Logbook(s):

• ELOG
• POLOG

Body:

The HVPS tank was topped to nominal 60 PSIG, completing task 10. Task 11 was repeated today, no SF6 leaks found. Details: https://logbooks.jlab.org/entry/4456961

The boundary work area around the gun HVPS tank has been removed.

We will not perform task 12. The DILO SF6 gas recovery cart will remain in the CEBAF injector tunnel, as a dedicated system for the gun HVPS SF6 tank.

The only remaining task is 13. I will remove the admin LOTO on Monday Sept 15.

Log Number: 4457008Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2025-09-11 14:44:11 The output from the myRestore execution was as follows: iocsoftrfcmtype systemEnum@2025-09-11 14:44 2(2) restored Execute: /usr/csite/certified/bin/ced2Epics -ced ced -A -i iocsoftrfcmtype (success) PVs modified: 53 Unassigned property [ILM2L08.Bias] Unassigned property [ILM2L09.Bias] Unassigned property [ILM2L10.Bias] Unassigned property [ILM2L11.Bias] PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 Procedure return status: Succes

Log Number: 4457007Logbook(s):

• ELOG

Body:

Ion pumps powered off from VIPAS02 TO VIPAA18 will begin to vent in the morning

Log Number: 4457006Logbook(s):

• ELOG
• INCLOG

Body:

Chassis's have been relocated to the top of the rack and all the cables have been reconnected
Task Complete

Log Number: 4457005Logbook(s):

• ELOG

Body:

Building 60 chilled water system and associated cooling tower equipment has been successfully switched back to automatic control. I will submit another Atlis when the subcontractor is ready to begin startup of the two new 800 tons chillers and associated equipment.

Log Number: 4457003Logbook(s):

• ELOG

Body:

2L18 waveguide turbo pump restarted, gate valve open turbo is at full speed.

Log Number: 4457001Logbook(s):

• ELOG

Body:

11th September work:
- finished SW corner RF separators as-found;
- C75-05 flanges inspection.

12th September work map:
- Hall D Target Cell as-found;
- (test lab) prepare for Hall A Moller Torus Magnet 4 coils alignment.

Log Number: 4457000Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2025-09-11 14:11:03 The output from the myRestore execution was as follows: iocnl26ibc systemEnum@2025-09-11 14:11 2(2) restored Execute: /usr/csite/certified/bin/ced2Epics -ced ced -A -i iocnl26ibc (success) PVs modified: 0 Unassigned property [ILM2L08.Bias] Unassigned property [ILM2L09.Bias] Unassigned property [ILM2L10.Bias] Unassigned property [ILM2L11.Bias] PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 Procedure return status: Success

Log Number: 4456998Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2025-09-11 13:10:29 The output from the myRestore execution was as follows: iocnl26ibc systemEnum@2025-09-11 13:10 2(2) restored Execute: /usr/csite/certified/bin/ced2Epics -ced ced -A -i iocnl26ibc (success) PVs modified: 0 Unassigned property [ILM2L08.Bias] Unassigned property [ILM2L09.Bias] Unassigned property [ILM2L10.Bias] Unassigned property [ILM2L11.Bias] PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 Procedure return status: Success

Log Number: 4456995Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2025-09-11 13:34:52 The output from the myRestore execution was as follows: iocsl1 <NOTE> Rf6Cryo: Provided macro *CAV* is never used <NOTE> Rf6Ops: Provided macro *IOC* is never used Rf6Cryo Execute: burtwb -f /cs/opshome/burt/REBOOT/rf/snap/iocsl1heatdisvINIT.snap (success) Execute: burtwb -f /cs/opshome/burt/REBOOT/rf/snap/iocsl1heatmodemanual.snap (success) Pause: 8 second(s) Rf06Cryo_heatset@2025-09-11 13:34 4(4) restored Pause: 8 second(s) Rf06Cryo_heatmode@2025-09-11 13:34

Log Number: 4456994Logbook(s):

• ELOG

Body:

Completed insulating vacuum leak checks on 2L02 & 2L04. Sprayed all 0-rings, relief plates, gauge cluster, tuner/top hat assemblies. No leaks detected. Minimal detectable leak was 1e-9 for both modules.
