Log Number: 4457133Logbook(s):

• ELOG

Body:

2L03 LLRF B12/B13/B14 work: Removed air plenums, 3 x X-connects in B14 and all cables connected to them (SSG removed their run-safe box cables for X connect removal.), power distribution chassis and started cutting out legacy 1.0 cables. Trashed the air plenums, RF crates and cabling in the new wire cages provided. Stored all power supplies in building 36 after tagging with zone and date. Brought interface chassis back to TEDF for spare cards and parts. L. Farrish installed MO/LO cables from the MO to the rack. All personal locks removed from MDP at end of day. Techs: C. Kerns, L. Farrish, A.

Log Number: 4457128Logbook(s):

• ELOG

Body:

CPS front panel taken to Machine Shop for modification. Parts inventory reviewed. Tech: S. Holben

Log Number: 4457127Logbook(s):

• ELOG

Body:

Finished containing the spliced cable from the 4 channels in NL01B01 to Rack NL01B11. Cables have been labeled and stored in the cable trench. Cables have been terminated with the proper ends for the 12A LNS. We still need to install the Chassis and connect the chassis to power and the network.

- Kissinger

Log Number: 4457126Logbook(s):

• ELOG

Entry Makers: radovicBody:

ESR valve box vacuum maintenance in progress
ESR2 adsorber o ring replaced and leak checked
ESR2 Main Compressor C4 mechanical maintenance in progress
North LINAC Zone 16 CAMAC to PLC upgrade in progress
ESR2 Instrumentation calibrations in progress

Log Number: 4457125Logbook(s):

• ELOG

Body:

Projects:
o CUP Upgrade – Continuing piping fab/install. Electrical work to continue on Wednesday.
o N/S Access Cooling Upgrade – Insulating new ductwork in NAB.
o LERF – Installing guardrails on the backside at the cryomodule delivery bay. Expected to finish same day.

Maintenance:
o Continuing LCW Pump PMs - @ SAB, SL pumps completed Friday. Starting PMs @ EA LCW pumps Monday.
o Continuing SA Cooling Tower cleaning and PMs.
o Reminder: Hall A truck ramp electrical panel work planned for Tuesday (2-day power outage expected).

Log Number: 4457124Logbook(s):

• ELOG

Body:

Non power PM's completed in NL zone 9,19. Contact switch change out in these zones underway.

Humphry,Janak,Diggs

Log Number: 4457123Logbook(s):

• ELOG

Body:

CT38 : Cell #1 complete. Cell #2 set for Monday AM.
All cells active / available for weekend.

Log Number: 4457122Logbook(s):

• ELOG

Tags:

• CED

Body: The following control system variables were updated because they were detected to differ from their CED property counter-parts.

Log Number: 4457120Logbook(s):

• ELOG

Body:

SA LCW : PMs complete for SL LCW pumps 1&2. WA LCW pump (3&4) PMs Monday AM.

Log Number: 4457118Logbook(s):

• ELOG

Body:

12th September work:
- Hall D Target Cell as-found;
- Prepare for Hall A Moller Torus Magnet 4 coils alignment.

15th September work map:
- Hall A Moller Torus Magnet 4 coils alignment.
- (test lab) prepare for 0L0R line as-found.

Log Number: 4457117Logbook(s):

• ELOG
• POLOG

Body:

turned VIP0I04A back on, turned off VIP0I03. No major change in blip rate, which is very low since beam stopped.
https://logbooks.jlab.org/entry/4457109

Log Number: 4457116Logbook(s):

• ELOG
• POLOG

Body:

Looked at supplies with Leo. VIP1I06 supply is behaving poorly - very noisy. The others are sitting at their baseline with some bit noise for pressure, while the current flickers around a bit more.
Things look fine other than the one supply that seems to be a lemon.

Log Number: 4457113Logbook(s):

• ELOG

Body:

Four cleanrooms staged upstream of 1L02 in preparation for plasma processing. Spoiled insulating vacuum
at 1L04,1L05 & 1L06.

Log Number: 4457110Logbook(s):

• ELOG

Body:

The PSS RF interface chassis cable has been removed from the cross-connect.

Log Number: 4457109Logbook(s):

• POLOG
• ELOG

Entry Makers: marcyBody:

Turned off VIP0I04A (chopper 2) ion pump Wednesday. The blips since beam has been off are small and infrequent. Turning off VIP0I04A doesn't seem to have changed anything.

I'll turn off VIP0I03 (chopper 1) for the weekend with VIP0I04A back on and see how that reacts.

Log Number: 4457107Logbook(s):

• ELOG

Body:

forgot to add, thanks to Shawn Frierson and Frank Humphry for helping move the clean rooms out the way to accommodate.

Log Number: 4457106Logbook(s):

• ELOG

Body:

Cable pull for Northwest Recombiner:(inst#3) in NL01 completed. In light of the flush rig still being hooked up to a magnet in the path of the Southwest Spreader installation we are going to delay that cable pull until next week.

Log Number: 4457105Logbook(s):

• ELOG
• SRFLOG

Body:

Injector
- VDP activation cart breakers fixed
- VDP0L06 activated successfully
- VDP0L03 scheduled for Monday morning

AE Line
- 3x beam pipes replaced
- VIPAE01, VIPAE01A, VIPAE02, VIPAT06, and VIPAT08A replaced
- Pump down started, will let work over weekend

Log Number: 4457104Logbook(s):

• ELOG

Body:

Replaced 3 pipes on the AE Line. Replaced Ion-pumps AE01, AE01A, AE02, AT06, and AT08A. Currently in the process of pumping the line back down and will pump over the weekend.

Log Number: 4457103Logbook(s):

• ELOG

Body:

All CARMS located in Hall B will be powered down this afternoon to continue calibrations.
