Log Number: 4537607Logbook(s):

• ELOG

Body:

SSG verified communitcation to BELS PLCs in preparation for tomorrows tests.

Log Number: 4537606Logbook(s):

• POLOG
• ELOG

Entry Makers: marcyBody:

Max was training me on the HV QE scan procedure and new spot move procedure.

Moved from (12750,19200) to (13400,18900), QE increased to .54 for Hall C, with other halls in similar ratios to what they were after the last spot move.

Found some improvements for procedure, successful test of procedure and system.

Log Number: 4537600Logbook(s):

• ELOG

Tags:

• Autolog

Body: saver ran from opsl06

Saved: marcy 08-04-26 11:25:14 {A:i B:1 C:5 E:1060 A=BS B=BS C=BS D=BS 0R08=0.00 0R08 dump in. A B C dump(s) in.

Log Number: 4537599Logbook(s):

• POLOG
• ELOG

Body: *New Spot* Spot Location: (13400.1,18900)

Laser Wavelength Atten Setting Laser Power Current HV PS Current QE PV Updated? Update Time/Reason Not Updated (nm) (W) (uA)

Log Number: 4537596Logbook(s):

• ELOG

Entry Makers: moserBody:

Figure 1: YBBS06.

Figure 2: YR9S05.

Figure 3: YBBS04.

Figure 4: ZAA7S03.

Log Number: 4537595Logbook(s):

• ELOG

Body:

Task is completed

Log Number: 4537594Logbook(s):

• ELOG

Entry Makers: moserBody:

Started with 1A08. One stack captured, ending with Figure 9: 9A16.

Log Number: 4537593Logbook(s):

• ELOG

Entry Makers: moserBody:

Part 2. Starting with 3A08.

Figure 31: 9A14. (stopping at the end of this stack). One more pt to go, 3 / 3.

Log Number: 4537592Logbook(s):

• ELOG
• INCLOG

Body:

IHA5C11 - preamp replaced, see log entry for details https://logbooks.jlab.org/entry/4537590

Log Number: 4537591Logbook(s):

• ELOG
• INCLOG

Body:

Completed camera replacement for viewers ITV1L06 & ITV1L22

Log Number: 4537589Logbook(s):

• ELOG
• INCLOG

Entry Makers: mmueller

Log Number: 4537590Logbook(s):

• ELOG
• INCLOG

Entry Makers: delacruzBody:

Before replacing the preamp, we cycled the harp using the preamp test signal. This produced a signal amplitude of 120mV, see fig. 1.

Replaced the preamp and used a test signal of 200mV (original test signal was 700mV), see fig. 2.

Cycled the harp using the modified preamp test signal, this produced a signal amplitude of 40mV. See figure 3.

Log Number: 4537588Logbook(s):

• ELOG

Entry Makers: moserBody:

Starting from 1A01, going by dipole stack.

32 pic limit. More coming in pt 2.

Figure 32 is 9A07 dipole.

Log Number: 4537587Logbook(s):

• ELOG

Body:

JC FLIR spread sheet updated with latest information. JA9A05 is a repeat offender. It was flushed 7/24 and flows checked. Todays readings were 139/141. It is being re-flushed today. Reason for this is unknown. Water quality???

Log Number: 4537583Logbook(s):

• ELOG

Body:

ePAS's 11474 & 11475 created as place holders for future flushing's if needed.

Log Number: 4537580Logbook(s):

• ELOG
• INCLOG

Entry Makers: delacruzBody:

Signal injected the pre-amps with a low current/voltage signal at 100mV. The previous signal injections were done with a 600mV signal.

Log Number: 4537579Logbook(s):

• ELOG

Body:

Tightened all connections in the tunnel.
Shunt Module Swapped again.

- Banks, Kissinger

Log Number: 4537578Logbook(s):

• ELOG
• RADLOG

Tags:

• Readme

Entry Makers: samariBody:

Steve Kennel from RadCon requested the Bld 95 TUN9 lock be removed and granted permission to do so. Hall C credited controls have been downgraded. Crew Chief authorized me to remove the bldg 95 TUN9 lock

Log Number: 4537576Logbook(s):

• ELOG
• INCLOG

Body:

Swapped out Ion Paks for VIP7S03A and VIP3S02.
Both showing good readbacks.

Log Number: 4537575Logbook(s):

• ELOG

Tags:

• Readme

Body: [figure:1] Always check the Authorization web application for the latest status: JLab Authorization Manager
