Log Number: 4495256Logbook(s):

• ELOG

Entry Makers: ywangBody:

1000-1020
Injector drifted, which caused the interception on apertures to increase. Corrected the drift.
Fig. 1: After correction, 400 laser attenuation generates 161nA cw beam for Hall B, 1.77 uA on A1, 0.73uA on A2, 2.67uA on MS
Fig. 2: Before correction, 657 laser attenuation generates 141nA cw beam for Hall B, 10.4 uA on A1, 2.37uA on A1, 8.61 uA on MS

Log Number: 4495254Logbook(s):

• ELOG

Tags:

• Autolog

Body: saver ran from opsl06

Saved: ywang 05-05-26 22:40:34 {A:i B:5 C:2 E:345 A=BS B=CW C=CW D=CW 0R08=7.08 No dumps in.

Log Number: 4495252Logbook(s):

• ELOG

Entry Makers: ywangBody:

1000-1020
Injector drifted, which caused the interception on apertures to increase.
Fig. 1: After correction, 400 laser attenuation generates 160nA cw beam for Hall B, 1.77 uA on A1, 0.73uA on A2, 2.67uA on MS
Fig. 2: Before correction, 672 laser attenuation generates 142nA cw beam for Hall B, 10.93 uA on A1, 2.5uA on A1, 8.7 uA on MS

Log Number: 4495244Logbook(s):

• ELOG

Body: IDDescriptionPeriodCause 16858Title:
Injector Work

Summary:
SME came in to work on the Injector to address A1 interception alarms.Duration:
30 minutes

Time Down:
05-May-2026 21:58

Time Up:

Log Number: 4495243Logbook(s):

• ELOG

Body: IDDescriptionPeriodCause 16858Title:
Injector Work

Summary:
SME came in to work on the Injector to address A1 interception alarms.Duration:
30 minutes

Time Down:
05-May-2026 21:58

Time Up:

Log Number: 4495241Logbook(s):

• ELOG

Tags:

• Autolog

Body: System UN-Masking for: BeamLossMonitor
User: lrichard
Areas: All

BeamLossMonitor Devices:
ILM0I07
ILM0L01A
ILM0L01B
ILM0L02
ILM2D00A
ILM2D00B
ILM0L04A
ILM0L04B
ILM0L05
ILM0L06A
ILM0L08
ILM0R01
ILM4D00
ILM0R03
ILM0R04
ILM0R06
ILM0R08
ILM0R09
ILM1L01
ILM1L02
ILM6R08
ILM3S00
ILM7S00
ILM9S00
ILM5S10
ILM5E03
ILM7S01
ILM9A01
ILM3E02
ILM5A01
ILM1A04
ILM1A06
ILM1A09
ILM5A10
ILM1A16
ILM1A19
ILM3R10
ILM9R07
ILM1R09
ILM2L03
ILM5R10
ILM5R05
ILM2L01
ILM2T09
IL

Log Number: 4495239Logbook(s):

• ELOG

Tags:

• Autolog

Body: System Masking for: BeamLossMonitor
User: alexs
Areas: All

BeamLossMonitor Devices:
ILM0I07
ILM0L01A
ILM0L01B
ILM0L02
ILM2D00A
ILM2D00B
ILM0L04A
ILM0L04B
ILM0L05
ILM0L06A
ILM0L08
ILM0R01
ILM4D00
ILM0R03
ILM0R04
ILM0R06
ILM0R08
ILM0R09
ILM1L01
ILM1L02
ILM6R08
ILM3S00
ILM7S00
ILM9S00
ILM5S10
ILM5E03
ILM7S01
ILM9A01
ILM3E02
ILM5A01
ILM1A04
ILM1A06
ILM1A09
ILM5A10
ILM1A16
ILM1A19
ILM3R10
ILM9R07
ILM1R09
ILM2L03
ILM5R10
ILM5R05
ILM2L01
ILM2T09
ILM8T09<

Log Number: 4495238Logbook(s):

• ELOG

Tags:

• Autolog

Body: Destination Masking to: HallB,HallC,HallD
User: alexs



Mismatch Detected - Gold Masks vs. Control System Values!!!
See Values [Calculated / Control Sys] Masked = 1, UnMasked = 0

Node Name : FSD_IN03_2
Ch. 8 Mismatch [ 0 / 1 ] VBV0L01B / BeamlineValve ... +

Log Number: 4495237Logbook(s):

• ELOG

Entry Makers: shrinerBody:

took setpoint

Log Number: 4495236Logbook(s):

• ELOG

Entry Makers: lrichardBody:

Possible Inj drift noticed when attempting 150nA to Hall B; A1 interception alarms.

Log Number: 4495235Logbook(s):

• ELOG

Tags:

• Autolog

Body: saver ran from opsl06
Data from: /usr/opdata/burt/allsnap/04-24-26_13:48:07
Restored file: /tmp/05-05-26_22:02:07.snap

Log Number: 4495233Logbook(s):

• ELOG

Tags:

• Autolog

Body: saver ran from opsl06
Data from: /usr/opdata/burt/allsnap/04-24-26_13:48:07
Restored file: /tmp/05-05-26_22:01:43.snap

Log Number: 4495232Logbook(s):

• ELOG

Tags:

• Autolog

Body: Destination Masking to: Injector
User: alexs



Mismatch Detected - Gold Masks vs. Control System Values!!!
See Values [Calculated / Control Sys] Masked = 1, UnMasked = 0

Node Name : FSD_IN03_2
Ch. 8 Mismatch [ 0 / 1 ] VBV0L01B / BeamlineValve ... +

Log Number: 4495222Logbook(s):

• ELOG
• SLOG

Body:

OPS reported that signals from iocse20 aren't appearing in myaplot after the IOC was rebooted.

Using IPM3H07A as an example signal.

It's available in EPICS

[63] theo@opsl90 > camonitor IPM3H07A.XPOS
IPM3H07A.XPOS 2026-05-05 21:14:40.323452 1.80363
IPM3H07A.XPOS 2026-05-05 21:14:43.306785 1.8293
IPM3H07A.XPOS 2026-05-05 21:14:46.306785 1.76872

However mya hasn't seen it reconnect in over an hour.

Log Number: 4495220Logbook(s):

• HBLOG
• BTLOG
• ELOG

Entry Makers: alexsBody:

The shift is most pronounced in the horizontal, but the entire hall line's orbit has shifted after running path length. Frustratingly, halo rates have remained relatively unchanged according to the archiver, but halo rate trips are now constant, and nowhere close to the set trip point of 1 million Hz. It makes me question why we use these diagnostics if the reported values appear to have no bearing on the actual trip point.

Log Number: 4495213Logbook(s):

• ELOG

Entry Makers: anthonyBody:

Log Number: 4495212Logbook(s):

• ELOG

Body: Calibration ParametersHall:DTarget: JD70-107 55um 45/135 degPass: 5.5Note: Calibrated On:2026-May-03 18:47Calibrated By: alexsFile:D-2026-05-03_1847_JD70-107_55um_45_135_deg_Pass-5.5.hcdIon ChamberExisting Setpoing (rads/hr)New Setpoint (rads/hr)

Log Number: 4495209Logbook(s):

• ELOG

Body: IDDescriptionPeriodCause 16857Title:
Recovering Hall C orbit after iocse20 drop

Summary:
iocse20, which houses Hall C orbit lock BPMs, dropped comms, but not before throwing off the hall's orbit to the point beam could not be sent without tripping ion chambers.

Log Number: 4495207Logbook(s):

• HBLOG
• ELOG

Entry Makers: alexsBody:

Log Number: 4495199Logbook(s):

• ELOG

Tags:

• Autolog

Body: saver ran from opsl632
Data from: /usr/opdata/burt/allsnap/05-05-26_15:44:12
Restored file: /tmp/05-05-26_20:12:38.snap
