Log Number: 4492839Logbook(s):

• DCLOG
• ELOG

Entry Makers: victorcBody:

20 Amp current got noisy after a cycle late swing shift.

Found some time to cycle it again to attempt to quiet it down, and it seemed to have worked.

Log Number: 4492838Logbook(s):

• ELOG

Body:

HYST AREA Version 7-0 has successfully cycled the following:

Magnets contained in the following file: /tmp/eDT_CMPQ_design_snapfile_5MOT5M.snap
MQN1S04
MQL1S05
MQB1S06
MQL1S07
MQL1S08
MQL1S09
MQB1S10

Total Time: 3.150 mins

Log Number: 4492837Logbook(s):

• ELOG
• BTLOG

Tags:

• Autolog

Body: eDT V2-40-4 snapfile - 1S quads on design
1S quads on design
hostname: opsl02
CED workspace: OPS
CED login_key: pro

Log Number: 4492836Logbook(s):

• ELOG
• BTLOG

Tags:

• Autolog

Body: eDT V2-40-4 Design Setpoints Download - Before 1E match
Before 1E match
hostname: opsl02
CED workspace: OPS
CED login_key: pro

Log Number: 4492835Logbook(s):

• ELOG

Entry Makers: kpriceBody:

Per advice from Optics on-call, 1E match should be redone before anything else

Log Number: 4492834Logbook(s):

• ELOG

Entry Makers: kpriceBody:

Round 1: horizontal and vertical beta. Reverting to try and wrangle y profile on 3S01 viewer.

Log Number: 4492833Logbook(s):

• ELOG

Entry Makers: victorcBody:

Log Number: 4492832Logbook(s):

• BTLOG
• ELOG

Entry Makers: dchriBody:

3S04 kinda stands out but overall looks good. Harp Scan at 3E is unwell.

Log Number: 4492831Logbook(s):

• ELOG
• BTLOG

Body:

Comments:

After another 30hz attempt. Not great results

Laser Used:

B Laser

Sigmas:

Peak 1 - x Sigma: 0.1828 Peak 2 - u Sigma: 0.8256 Peak 3 - y Sigma: 1.1242

Log Number: 4492830Logbook(s):

• ELOG
• BTLOG

Body: Fopt results from /usr/ntfs/public/optics/diforb/26apr300157
Comment: After 2R recombiner match
HOSTNAME: opsl01
CED WORKSPACE: OPS CED LOGIN KEY: pro
MYA DEPLOYMENT: ops
CONFIG PATH: /cs/prohome/apps/q/QTSnyder_QT5/1-2/fileio/config/cs.conf
DIFORB PATH: /usr/ntfs/public/optics/diforb

Log Number: 4492829Logbook(s):

• ELOG

Tags:

• Autolog

Body: Fopt 7.9 completed successfully. The runtime settings include a sample count of 15, a minimum current of 4, and an operating regime of Standard with Excitation in 1S Region. The corrector and RF kicks applied were 0.488208 and 0.488208 volts respectively. The max. amplitude setting was 1 millimeters. The files for this run were saved in the directory /cs/opshome/hlapps/optics/diforb/26apr300157. The X and Y stability of the machine during the run was 0.053238 and 0.0401762 (mm) respectively.

Log Number: 4492828Logbook(s):

• ELOG
• RFLOG

Entry Makers: victorcBody:

Attempting to turn this cavity on results in failute around the DsetRamp step. No matter what we set the DSET Begin setpoint to, the value automatically reverts to a value of ~210 to 220 during the one button turn on sequence. The CRFP ends up spiking around these DSET values and the cavity trips off.

Log Number: 4492827Logbook(s):

• BTLOG
• ELOG

Entry Makers: dchriBody:

FIG. 2
3S04 Atten increased by +40

Log Number: 4492826Logbook(s):

• ELOG
• HBLOG

Body:

Comments:

Still not happy. perhaps viewer walk will provide more insight

Laser Used:

B Laser

Sigmas:

Peak 1 - x Sigma: 0.2445 Peak 2 - u Sigma: 0.7455 Peak 3 - y Sigma: 0.8015

Log Number: 4492825Logbook(s):

• ELOG
• BTLOG

Body: Fopt results from /usr/ntfs/public/optics/diforb/26apr300120
Comment: After 30hz and 2A21 corrections
HOSTNAME: opsl02
CED WORKSPACE: OPS CED LOGIN KEY: pro
MYA DEPLOYMENT: ops
CONFIG PATH: /cs/prohome/apps/q/QTSnyder_QT5/1-2/fileio/config/cs.conf
DIFORB PATH: /usr/ntfs/public/optics/diforb

Log Number: 4492824Logbook(s):

• ELOG

Tags:

• Autolog

Body: Fopt 7.9 completed successfully. The runtime settings include a sample count of 15, a minimum current of 4, and an operating regime of Standard with Excitation in 1S Region. The corrector and RF kicks applied were 0.488208 and 0.488208 volts respectively. The max. amplitude setting was 1 millimeters. The files for this run were saved in the directory /cs/opshome/hlapps/optics/diforb/26apr300120. The X and Y stability of the machine during the run was 0.0660228 and 0.0350335 (mm) respectively.

Log Number: 4492823Logbook(s):

• ELOG

Entry Makers: kpriceBody:

Strengthened MQC2A21 +100 G to correct horizontal dispersion into 3 linac.

Log Number: 4492822Logbook(s):

• ELOG
• BTLOG

Body:

Comments:

sad swipe

Laser Used:

B Laser

Sigmas:

Peak 1 - x Sigma: 0.2182 Peak 2 - u Sigma: 0.7497 Peak 3 - y Sigma: 0.7442

Log Number: 4492821Logbook(s):

• ELOG

Tags:

• Autolog

Body: Fopt 7.9 completed successfully. The runtime settings include a sample count of 15, a minimum current of 4, and an operating regime of Standard with Excitation in 1S Region. The corrector and RF kicks applied were 0.488208 and 0.488208 volts respectively. The max. amplitude setting was 1 millimeters. The files for this run were saved in the directory /cs/opshome/hlapps/optics/diforb/26apr300106. The X and Y stability of the machine during the run was 0.0596688 and 0.0395422 (mm) respectively.

Log Number: 4492819Logbook(s):

• ELOG
• BTLOG

Body:

Comments:

After laser phase adjustment

Laser Used:

B Laser

Sigmas:

Peak 1 - x Sigma: 0.2008 Peak 2 - u Sigma: 0.2316 Peak 3 - y Sigma: 0.2452
