Log Number: 4475129Logbook(s):

• POLOG
• ELOG

Entry Makers: mamunchgarciaBody:

Excercising Gun HV ramp down/up/down to verify the HV and 15 deg DP setpoint and limit changes are in effect. After this we will go to InjSB to update the 15 deg DP interlock.

Log Number: 4475125Logbook(s):

• ELOG
• POLOG

Tags:

• Autolog

Body:

Log Number: 4475111Logbook(s):

• ELOG

Body:

Cryo Operations concurs with the 3/11 date, contingent on system stability after RF-Off transition. Cryo's procedure remains as previous comment established.

Log Number: 4475104Logbook(s):

• ELOG

Entry Makers: mockBody:

Channel access open.

Log Number: 4475088Logbook(s):

• ELOG
• POLOG

Tags:

• Autolog

Body:

Log Number: 4475087Logbook(s):

• ELOG

Body:

Investigated R/S box "RS03" in UITF for "safe light not visible" found the safe light bulbs/LED's are functioning but "dim". While investigating one of the Bulbs/sockets failed. Need to replace bulbs and some of the bulb sockets. Will schedule the repairs based on the UITF schedule (need access to cave for repair).

Log Number: 4475086Logbook(s):

• POLOG
• ELOG

Body:
Record

Log Number: 4475085Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
2L23-8
Username: jkt
Date/Time: 03-09-26_10:24:02
RF Status: Good
Tuner Status: Good
Comment: Filament Board replaced. https://logbooks.jlab.org/entry/4474407
Special Instructions:

Maintenance Tag: Component: Filament Board

Log Number: 4475084Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
2L23-2
Username: jkt
Date/Time: 03-09-26_10:24:02
RF Status: Good
Tuner Status: Good
Comment: Filament Board replaced. https://logbooks.jlab.org/entry/4474407
Special Instructions:

Maintenance Tag: Component: Filament Board

Log Number: 4475083Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
2L23-2
Username: jkt
Date/Time: 03-09-26_10:23:29
RF Status: Good
Tuner Status: Good
Comment: Filament board replaced. https://logbooks.jlab.org/entry/4474407
Special Instructions:

Maintenance Tag: Component: Filament Board

Log Number: 4475082Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
2L23-3
Username: jkt
Date/Time: 03-09-26_10:22:49
RF Status: Good
Tuner Status: Good
Comment: resolved with battery on DSP control board. https://logbooks.jlab.org/entry/4474407
Special Instructions:

Maintenance Tag: Component: Other

Log Number: 4475081Logbook(s):

• ELOG
• RFLOG

Tags:

• Autolog

Body:

The following cavity histories have been updated:
2L23-1
Username: jkt
Date/Time: 03-09-26_10:22:12
RF Status: Good
Tuner Status: Good
Comment: resolved with battery on DSP control board. https://logbooks.jlab.org/entry/4474407
Special Instructions:

Maintenance Tag: Component: Other

Log Number: 4475079Logbook(s):

• BTLOG
• ELOG

Body:

Approved. We'll also need to update the CED to reflect the new gun voltage.

Log Number: 4475078Logbook(s):

• ELOG

Entry Makers: mockBody:

As requested by CIS.
They calculated a new value for this magnet to be set. FSD thresholds updated as well.
Fig. 1) Before
Fig. 2) After

Log Number: 4475076Logbook(s):

• POLOG
• ELOG

Entry Makers: mamunchgarciaBody:

FSD window set point for 15 deg dipole (MDR1I02 Low Noise Supply) for 140 kV Gun operation is updated.

Crew chief changed the MDR1I02 setpoint from -2.6 A to -2.08 A.

Max Bruker provided the new set point for 140 kVas -2.08 A. High and low limits are set as 20% of the nominal per Joe Grames instruction.

Per Scott Higgins request he is been notified about this change.

Log Number: 4475075Logbook(s):

• ELOG
• RADLOG

Entry Makers: bbarkerBody:

Log Number: 4475071Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2026-03-09 07:24:32 The output from the myRestore execution was as follows: iocw6se1 systemEnum@2026-03-09 07:24 2(2) restored seebpm@2026-03-09 07:24 1933(1933) restored Pause: 30 second(s) SEE_BURT 43(43) restored Execute: /usr/csite/certified/bin/ced2Epics -ced ced -A -i iocw6se1 (success) PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 PVs modified: 0 Procedure return status: Success

Log Number: 4475069Logbook(s):

• ELOG
• SLOG

Tags:

• Autolog

Body: restorelib 3.0.1 Target restore date was 2026-03-09 07:00:00 The output from the myRestore execution was as follows: iocw6se1 systemEnum@2026-03-09 07:00 2(2) restored seebpm@2026-03-09 07:00 The following are not available in EPICS IOCW6SE1:CTsub.STR1 IPM2R01.XNIN IPM2R01.XNIR IPM2R01.XNIX IPM2R01.XPIX IPM2R01.YNIN IPM2R01.YNIR IPM2R01.YNIX IPM2R01.YPIN IPM2R01.YPIX IPM2R02.XNIN IPM2R02.XNIR IPM2R02.XNIX IPM2R02.XPIX IPM2R02.YNIN IPM2R02.YNIR IPM2R02.YNIX IPM2R02.YPIN IPM2R02.YPIX IPM2R03.XNIN IPM2R03.XNIR IPM2R03.XNIX IPM2R0

Log Number: 4475067Logbook(s):

• POLOG
• ELOG

Entry Makers: brukerBody:

Gammas and betas for 200 keV and 140 keV so I don't have to recalculate every time.

>>> gamma
array([1.39138943, 1.2739726 ])
>>> beta
array([0.69531404, 0.61956388])
>>> beta * gamma
array([0.96745261, 0.78930741])

The factor between the two (for magnet scaling) is:
1.2256981170372578

Log Number: 4475066Logbook(s):

• POLOG
• ELOG

Entry Makers: mamunchgarciaBody:

Gun comparator set points in HV Gun Comparator in FSD is updated for 140 kV operation.
