BLA trips

Recent Log Entries -

Log Number: 3827970Logbook(s): Entry Makers: beneschBody:

A BLA trip just occurred so I looked at the signals. Instantaneous loss on the scale shown in figure 1. Constant in figure 2 is 1.5 uA so I don't see why there should have been a trip with 24 uA to C only. Integrated loss and the two currents are on a 0-1250 unit scale. There are spikes in figure 1 which exceed 1.5 uA in either direction so those trips should have occurred. Figure 3 shows BLA trips in light purple.

lem info screens

Recent Log Entries -

Log Number: 3827966Logbook(s): Entry Makers: beneschBody:

Figure 1 reflects the three reductions I just made to ODVH on the cavities with highest true arc faults. It also shows that the energy lock zone, 1L19, is running low in general. Change fudge slightly?

Figure 2 reflects the one ODVH reduction just made. Energy lock zone 2L19 is running a bit higher than lem would set. Increase fudge to 0.96 or even 0.965 since 2L19 is 2 MV/m or 1 MeV/c high? fudge had been at 0.96 for the first five days of the month.

Figures 4-7 show options for both NL and SL.

TrueArc Offenders

Recent Log Entries -

Log Number: 3827953Logbook(s): Body: TrueArc Offenders for the last 24.00 hours
Aug/14/2020 09:42 to Aug/15/2020 09:42

CAVITY TRUEARCS TRIPRATE
------------------------------------------------
1L03-3 9 0.38
1L15-7 6 0.25
2L17-8 6 0.25
1L15-6 5 0.21
1L17-1 4 0.17
1L18-7 4 0.17
1L20-7 4 0.17
2L17-1 4 0.17
2L19-8 4 0.17
1L02-7 3 0.12
1L03-8 3 0.12
1L09-4 3 0.12

Operator SIGN IN

Recent Log Entries -

Log Number: 3827944Logbook(s): Body:  ACCELERATOR OPERATOR SIGN IN FORM OPERATOR:    Gauthier
DATE:             08/15/2020
SHIFT:               Day

The operator has read the following:
  • ELOG
  • PD Shift Plan
  • Radiation Surveys for PSS Segments in Controlled Access
  • PSS Log

Operator SIGN IN

Recent Log Entries -

Log Number: 3827911Logbook(s): Body:  ACCELERATOR OPERATOR SIGN IN FORM OPERATOR:    Carlino
DATE:             08/15/2020
SHIFT:               Day

The operator has read the following:
  • ELOG
  • PD Shift Plan
  • Radiation Surveys for PSS Segments in Controlled Access
  • PSS Log
